2015 Ford Econoline Commercial Chassis

2015 Ford Econoline Commercial Chassis

E-350 Stripped Chassis 138"

View more styles
Close

All 2015 Ford Econoline Commercial Chassis Styles

Style NameFuel TypeDrive TypeMPGMSRP
E-350 Stripped Chassis 138"Flexible FuelRear Wheel DriveCity: 0
Hwy: 0
$25,370.00
E-350 Stripped Chassis 158"Flexible FuelRear Wheel DriveCity: 0
Hwy: 0
$25,620.00
E-350 Stripped Chassis 176"Flexible FuelRear Wheel DriveCity: 0
Hwy: 0
$26,120.00
E-450 Stripped Chassis 158"Flexible FuelRear Wheel DriveCity: 0
Hwy: 0
$27,370.00
E-450 Stripped Chassis 176"Flexible FuelRear Wheel DriveCity: 0
Hwy: 0
$27,870.00

2WD Light Duty Chassis-Cab Trucks
Rear Wheel Drive
Base MSRP: $25,370.00
Invoice: $23,404.00
Hwy MPG: N/A mpg
City MPG: N/A mpg

Pricing

To get up to date 2015 Ford Econoline Commercial Chassis values, we highly recommend you evaluate and compare the Retail, Private Party, and/or Trade-In Values from the following reputable market pricing providers:

Vehicle

Emissions
Tons/yr of CO2 Emissions @ 15K mi/yearN/A
EPA Greenhouse Gas ScoreN/A

Chassis

Weight Information
Gross Axle Wt Rating - Front4200 lbs
Gross Axle Wt Rating - Rear7800 lbs
Curb Weight - Front2246 lbs
Curb Weight - Rear2168 lbs
Option Weight - Front0.00 lbs
Option Weight - Rear0.00 lbs
Reserve Axle Capacity - Front1954.00 lbs
Reserve Axle Capacity - Rear5632.00 lbs
As Spec'd Curb Weight4414.00 lbs
As Spec'd Payload7086.00 lbs
Maximum Payload Capacity7086.00 lbs
Gross Combined Wt Rating13000 lbs
Gross Axle Weight Rating12000.00 lbs
Curb Weight4414.00 lbs
Reserve Axle Capacity7586.00 lbs
Total Option Weight0.00 lbs
Gross Vehicle Weight Rating11500.00 lbs
Trailering
Dead Weight Hitch - Max Trailer Wt.1500 lbs
Dead Weight Hitch - Max Tongue Wt.150 lbs
Wt Distributing Hitch - Max Trailer Wt.1500 lbs
Wt Distributing Hitch - Max Tongue Wt.150 lbs
Maximum Trailering Capacity1500 lbs
Frame
Frame TypeN/A
Sect Modulus Rails OnlyN/A
Frame RBMN/A
Frame StrengthN/A
Frame ThicknessN/A
Suspension
Suspension Type - FrontOther
Suspension Type - RearLeaf
Spring Capacity - Front4200 lbs
Spring Capacity - Rear7800 lbs
Axle Type - FrontIndependent
Axle Type - RearRigid Axle
Axle Capacity - Front5000 lbs
Axle Capacity - Rear7800 lbs
Axle Ratio (:1) - Front4.10
Axle Ratio (:1) - Rear4.10
Shock Absorber Diameter - FrontN/A
Shock Absorber Diameter - RearN/A
Stabilizer Bar Diameter - FrontN/A
Stabilizer Bar Diameter - RearN/A
Tires
Front Tire Order CodeT67
Rear Tire Order CodeT67
Front Tire SizeLT225/75SR16
Rear Tire SizeLT225/75SR16
Front Tire Capacity5000 lbs
Rear Tire Capacity9460 lbs
Spare Tire CapacityN/A
Revolutions/Mile @ 45 mph - Front709
Revolutions/Mile @ 45 mph - Rear709
Revolutions/Mile @ 45 mph - SpareN/A
Wheels
Front Wheel Size16 X 6 in
Rear Wheel Size16 X 6 in
Front Wheel MaterialSteel
Rear Wheel MaterialSteel
Steering
Steering TypeRe-Circulating Ball
Steering Ratio (:1), OverallN/A
Steering Ratio (:1), On CenterN/A
Steering Ratio (:1), At LockN/A
Turning Diameter - Curb to Curb48.6 ft
Turning Diameter - Wall to WallN/A
Brakes
Brake Type4-Wheel Disc
Brake ABS System4-Wheel
Brake ABS System (Second Line)4-Wheel
Disc - Front (Yes or )Yes
Disc - Rear (Yes or )Yes
Front Brake Rotor Diam x Thickness13.6 in
Rear Brake Rotor Diam x Thickness13.6 in
Fuel Tank
Fuel Tank Capacity, Approx40 gal
Aux Fuel Tank Capacity, ApproxN/A
Fuel Tank LocationN/A
Aux Fuel Tank LocationN/A

Powertrain

Transmission
DrivetrainRear Wheel Drive
Trans Order Code44T
Trans Type5
Trans Description Cont.Automatic w/OD
First Gear Ratio (:1)3.11
Second Gear Ratio (:1)2.22
Third Gear Ratio (:1)1.55
Fourth Gear Ratio (:1)1.00
Fifth Gear Ratio (:1)0.71
Reverse Ratio (:1)2.88
Clutch SizeN/A
Trans Power Take OffN/A
Final Drive Axle Ratio (:1)N/A
Transfer Case ModelNone
Transfer Case Gear Ratio (:1), HighN/A
Transfer Case Gear Ratio (:1), LowN/A
Transfer Case Power Take OffNo
Mileage
EPA Fuel Economy Est - HwyN/A
Cruising Range - CityN/A
EPA Fuel Economy Est - CityN/A
Fuel Economy Est-CombinedN/A
Cruising Range - HwyN/A
Engine
Engine Order Code99L
Engine TypeRegular Unleaded V-8
Displacement5.4 L/330
Fuel SystemSequential MPI
SAE Net Horsepower @ RPM255 @ 4500
SAE Net Torque @ RPM350 @ 2500
Engine Oil CoolerNone
Electrical
Cold Cranking Amps @ 0° F (Primary)650
Cold Cranking Amps @ 0° F (2nd)650
Cold Cranking Amps @ 0° F (3rd)N/A
Maximum Alternator Capacity (amps)120
Cooling System
Total Cooling System CapacityN/A

Dimensions

Interior Dimensions
Passenger Capacity1
Front Head RoomN/A
Front Leg RoomN/A
Front Shoulder RoomN/A
Front Hip RoomN/A
Second Head RoomN/A
Second Leg RoomN/A
Second Shoulder RoomN/A
Second Hip RoomN/A
Exterior Dimensions
Wheelbase138 in
Length, Overall w/o rear bumper232.7 in
Length, Overall w/rear bumperN/A
Length, OverallN/A
Width, Max w/o mirrorsN/A
Height, OverallN/A
Overhang, FrontN/A
Overhang, Rear w/o bumper68.5 in
Front Bumper to Back of CabN/A
Cab to AxleN/A
Cab to End of FrameN/A
Ground to Top of Load FloorN/A
Ground to Top of FrameN/A
Frame Width, RearN/A
Ground Clearance, FrontN/A
Ground Clearance, RearN/A
Body Length0.00 ft
Cab to BodyN/A
Cargo Area Dimensions
Cargo Box Width @ Top, RearN/A
Cargo Box Width @ FloorN/A
Cargo Box Width @ WheelhousingsN/A
Cargo Box (Area) HeightN/A
Tailgate WidthN/A
Cargo VolumeN/A
Ext'd Cab Cargo VolumeN/A

Warranty Information

Basic:
3 Years/36,000 Miles

Drivetrain:
5 Years/60,000 Miles

Corrosion:
5 Years/Unlimited Miles

Roadside Assistance:
5 Years/60,000 Miles
